| Output Signal | Standard 2-wire: 4-20 mA / Vs = 8-32 Vdc
Optional 3-wire: 0-10 V / Vs = 14-30 Vdc
Optional 3-wire ratiometric: Vsig = 0.5-4.5 V / Vs = 5 ± 0.5 Vdc |
| | |
| Accuracy | ±0.5% FSO |
| | |
| Permissible Load | 2-wire: Rmax = [(Vs - Vs min) / 0.02] Ohm
3-wire: Rmin = 10 kOhm |
| | |
| Influence Effects | Supply: 0.05% FSO / 10 V
Load: 0.05% FSO / kOhm |
| | |
| Response Time | 2-wire: <10 msec
3-wire: <3 msec |
| | |
Measuring Rate
| 1 kHz
|
| |
Thermal Error
| <±0.3% FSO / 10K in compensated range 32°F to 158°F (0°C to 70°C)
|
| |
Permissible Temperatures
| Medium: -13°F to 185°F (-25°C to 85°C)
Electronics environment: -13°F to 185°F (-25°C to 85°C)
Storage: -40°F to 185°F (-40°C to 85°C)
|
| |
Short-circuit Protection
| Permanent
3-wire ratiometric: None |
| |
Reverse Polarity Protection
| No damage. No function.
|
| |
Electromagnetic Protection
| Emission and immunity according to EN 61326
|
| |
Stability
| Vibration: 10 g, 25 Hz to 2 kHz according to DIN EN 60068-2-6
Shock: 100 g / 1 msec according to DIN EN 60068-2-27
|
| |
Pressure Port / Housing
| 304 SS
|
| | |
Wetted Parts
| Seals: FKM (Viton® standard)
Diaphragm: 316L SS |
| | |
Weight
| 120 g
|
| | |
Current Consumption
| 2-wire: 25 mA max
3-wire voltage: 5 mA (short-circuit current 20 mA)
3-wire ratiometric: 1.5 mA |
| | |
CE Conformity
| EMC directive: 2004/108/EC |
