Lay-In Wireway

NEMA 1

Application

Construction designed to ensure electrical continuity and to permit fast and easy indoor installation of multiple wireway runs.

Standards

UL-50 Type 1
cUL Type 1
Complies with
- IEC 6029, IP20

Construction

Formed from 16 or 14 gauge steel.
Straight sections, Fittings and Joiners make it possible
to lay in continuous run of cables.
CWST Series are hinged on 24” centers (max)
Concentric knockouts (1/2”, 3/4” conduit size) are standard on straight lengths where noted.
Knockouts (when provided) are on 12” centers.
Screw cover sections do not have knockouts.
Barriers to separate different cable voltages are available
as an accessory.
Unobstructed interior speeds up laying of cables.
Joiner included with the straight sections.
Optional hanger brackets allow for vertical and horizontal
mounting.

Finish

Sections and components are finished in ANSI 61 gray.
Couplings are unpainted galvanized.

Screw Cover	2.5 x 2.5	4 x 4	6 x 6	8 x 8	10 x 10	12 x 12
Straight Section 12”	CWSC212NK	CWSC412NK	CWSC612NK	CWSC812NK	CWSC1012NK	CWSC1212NK
Straight Section 18”	-	CWSC418NK	CWSC618NK	CWSC818NK	-	-
Straight Section 24”	CWSC224NK	CWSC424NK	CWSC624NK	CWSC824NK	CWSC1024NK	CWSC1224NK
Straight Section 36”	CWSC236NK	CWSC436NK	CWSC636NK	CWSC836NK	CWSC1036NK	CWSC1236NK
Straight Section 48”	CWSC248NK	CWSC448NK	CWSC648NK	CWSC848NK	CWSC1048NK	CWSC1248NK
Straight Section 60”	CWSC260NK	CWSC460NK	CWSC660NK	CWSC860NK	CWSC1060NK	CWSC1260NK
Straight Section 72”	-	CWSC472NK	CWSC672NK	CWSC872NK	CWSC1072NK	-
Straight Section 120”	CWSC2120NK	CWSC4120NK	CWSC6120NK	CWSC8120NK	CWSC10120NK	CWSC12120NK

Hinged Cover	2.5 x 2.5	4 x 4	6 x 6	8 x 8	10 x 10	12 x 12
Straight Section 12”	CWST212	CWST412	CWST612	CWST812	CWST1012NK	CWST1212NK
Straight Section 18”		CWST418NK	CWST618NK	CWST818NK	-	-
Straight Section 24”	CWST224	CWST424	CWST624	CWST824	CWST1024NK	CWST1224NK
Straight Section 36”	CWST236	CWST436	CWST636	CWST836	CWST1036NK	CWST1236NK
Straight Section 48”	CWST248	CWST448	CWST648	CWST848	CWST1048NK	CWST1248NK
Straight Section 60”	CWST260	CWST460	CWST660	CWST860	CWST1060NK	CWST1260NK
Straight Section 72”	CWST272	CWST472	CWST672	CWST872	CWST1072NK	CWST1272NK
Straight Section 96”	CWST296	CWST496	CWST696	CWST896	CWST1096NK	CWST1296NK
Straight Section 120”	CWST2120	CWST4120	CWST6120	CWST8120	CWST10120NK	CWST12120NK

Accessories	2.5 x 2.5	4 x 4	6 x 6	8 x 8	10 x 10	12 x 12
Straight Section Barrier 12”	CWBA212	CWBA412	CWBA612	CWBA812	CWBA1012	CWBA1212
Straight Section Barrier 18”	-	CWBA418	CWBA618	CWBA818	-	-
Straight Section Barrier 24”	CWBA224	CWBA424	CWBA624	CWBA824	CWBA1024	CWBA1224
Straight Section Barrier 36”	CWBA236	CWBA436	CWBA636	CWBA836	CWBA1036	CWBA1236
Straight Section Barrier 48”	CWBA248	CWBA448	CWBA648	CWBA848	CWBA1048	CWBA1248
Straight Section Barrier 60”	CWBA260	CWBA460	CWBA660	CWBA860	CWBA1060	CWBA1260
Straight Section Barrier 72”	CWBA272	CWBA472	CWBA672	CWBA872	CWBA1072	CWBA1272
Straight Section Barrier 96”	CWBA296	CWBA496	CWBA696	CWBA896	CWBA1096	CWBA1296
Straight Section Barrier 120”	CWBA2120	CWBA4120	CWBA6120	CWBA8120	CWBA10120	CWBA12120

Elbow 90 degrees	CWEL290	CWEL490	CWEL690	CWEL890	CWEL1090	CWEL1290
Elbow 45 degrees	CWEL245	CWEL445	CWEL645	CWEL845	CWEL1045	CWEL1245
Elbow 22.5 degrees	CWEL222	CWEL422	CWEL622	CWEL822	CWEL1022	CWEL1222

Tee Fitting	CWTF2	CWTF4	CWTF6	CWTF8	CWTF10	CWFT12
Cross Fitting	CWCF2	CWCF4	CWCF6	CWCF8	CWCF10	CWCF12

Reducer 4 x 4 to 2.5 x 2.5	-	CWRD42	-	-	-	-
Reducer 6 x 6 to 4 x 4	-		CWRD64	-	-	-
Reducer 8 x 8 to 6 x 6	-	-	-	CWRD86	-	-
Reducer 10 x 10 to 8 x 8	-	-	-	-	CWRD108	-
Reducer 12 x 12 to 8 x 8	-	-	-	-	-	CWRD128
Reducer 12 x 12 to 10 x 10	-	-	-	-	-	CWRD1210

Bracket Hanger Ceiling Type	CWHD2	CWHD4	CWHD6	CWHD8	CWHD10	CWHD12
Bracket Hanger Wall Type	CWHW2	CWHW4	CWHW6	CWHW8	CWHW10	CWHW12

Closing Plate	CWCP2	CWCP4	CWCP6	CWCP8	CWCP10	CWCP12
Adapter (Box Connector)	CWAD2	CWAD4	CWAD6	CWAD8	CWAD10	CWAD12
Joiner	CWJO2	CWJO4	CWJO6	CWJO8	CWJO10	CWJO12
Telescope Fitting	CWTL2	CWTL4	CWTL6	CWTL8	CWTL10	CWTL12
